Synteny visualization (a polyploid against itself)

TL;DR: an allopolyploid carries several near-complete copies of its own genome, so one assembly goes on both axes of a dotplot. jcvi chains a protein self-alignment into syntenic anchors, kaks_from_pairs.py measures dN and dS on each anchor, and colorBy: dnds paints selection pressure across the whole karyotype.

Prerequisites

jcvi
DIAMOND
python3 with biopython
wget
node, for the JBrowse CLI

jcvi builds C extensions and will not install against every python. If pip install jcvi fails compiling them, uv venv --python 3.12 followed by uv pip install jcvi biopython gets an interpreter it does build on. DIAMOND ships a static binary in its GitHub releases.

Where the data comes from

Oat cultivar Williams (Peng et al. 2022), annotated by Ensembl Plants release 63 as GCA_951802345.1.

the annotation the self-alignment runs on: https://ftp.ensemblgenomes.ebi.ac.uk/pub/plants/release-63/gff3/avena_sativa_gca951802345v1cm/Avena_sativa_gca951802345v1cm.Asativa_cv_Williams_v1.0.63.gff3.gz
the CDS the proteome is translated from: https://ftp.ensemblgenomes.ebi.ac.uk/pub/plants/release-63/fasta/avena_sativa_gca951802345v1cm/cds/Avena_sativa_gca951802345v1cm.Asativa_cv_Williams_v1.0.cds.all.fa.gz
the wheat panel's annotations (Aegilops tauschii, sorghum, bread wheat) and the sorghum-anchored Compara homology table, same release: https://ftp.ensemblgenomes.ebi.ac.uk/pub/plants/release-63/

Oat's three subgenomes and their homoeologs

Oat (Avena sativa) is an allohexaploid: three diploid grasses hybridized and the result kept all three genomes. Its 21 chromosomes are seven homoeologous groups of three, one chromosome per subgenome (A, C and D), and nearly every gene exists three times.

The copies of one ancestral gene across those subgenomes are homoeologs. A table of them is a comparative dataset drawn from a single assembly, so the same MCScanBlocksAdapter that stacks several genomes puts one genome on both axes.

Two things are then worth asking of it. Where the copies sit relative to each other is the karyotype, and where a segment has moved between homoeologous groups it leaves the diagonal. How hard selection has held each pair together is dN/dS, which is a per-pair measurement and therefore a colour.

Producing the data

Gene models, a proteome, and chromosome sizes

jcvi turns the GFF3 into the BED the adapter also reads, one primary transcript per gene:

python -m jcvi.formats.gff bed --type=mRNA --key=transcript_id \
  --primary_only oat.gff3.gz -o oat.all.bed
awk -F'\t' '$1 ~ /^[1-7][ACD]$/' oat.all.bed > oat.bed

The awk keeps the 21 chromosomes and drops the unplaced contigs.

The proteome is translated from the CDS, which keeps one namespace from the BED through the anchors to the codon alignments: Ensembl's protein FASTA is keyed on protein ids, and every other id in this pipeline is a transcript id. The end-to-end script has the loop.

The assembly is a ChromSizesAdapter built from the GFF3's own ##sequence-region header, which is all a gene-level view reads. See assemblies without sequence.

Syntenic anchors from a self-alignment

Naming one prefix twice is a self-comparison, which jcvi handles: it drops the gene-against-itself diagonal, then chains what is left into syntenic blocks.

diamond makedb --in oat.pep -d oat.pep
diamond blastp --threads 14 --query oat.pep --db oat.pep --out oat.oat.last \
  --max-target-seqs 20 --evalue 1e-10 --outfmt 6
python -m jcvi.compara.catalog ortholog --no_strip_names --dbtype prot \
  --align_soft diamond_blastp --self_remove 100 --no_dotplot oat oat

Two flags carry the run.

--self_remove defaults to 98 and discards every hit at or above that percent identity. Oat's A-D homoeologs are recent enough to sit above it, so this run sets 100, where only a perfectly identical protein pair is dropped.

--no_strip_names keeps the ids byte-identical to the BED, which is what the adapter joins the two sides on.

The alignment is the long step, over an hour on every core here: Ensembl's annotation of this assembly calls a large number of transcripts, and this is a proteome against itself. Running it separately keeps DIAMOND at default sensitivity, which finds homoeologs this recent; jcvi's own call uses --ultra-sensitive --max-target-seqs 1000, for orthologs across a hundred million years. jcvi picks the file up by name and skips its alignment step.

Chaining is what the synteny pipeline adds: an anchor survives only where its neighbours agree. A gene family's best hit lands wherever the family's closest member is, and that off-diagonal noise looks like the translocated segments this plot is about.

A self-comparison also chains each subgenome's own tandem and segmental duplicates, which are paralogs. A homoeolog pair has its two ends on different subgenomes, which the chromosome name says, so the script filters on it.

Take oat.oat.anchors, and leave the oat.oat.lifted.anchors written beside it. Liftover recruits extra pairs near an established block, and on this genome those pairs are a different population: their median dS is several times that of the chained ones, the grasses' ancient duplication and gene families.

dN and dS on each anchor

Ensembl declares dn and ds in every homology export and fills neither, in any division, so they are computed here:

python3 kaks_from_pairs.py oat.pairs.tsv oat.cds.fa.gz \
  --key record --min-syn-subs 3 -o oat.kaks.tsv

kaks_from_pairs.py aligns each pair as protein, back-translates to codons so that nothing shifts frame, and runs Nei-Gojobori. --key record reads the CDS by transcript id, so each rate is measured on the pair the synteny was called on.

It reports the pairs it could not measure. Two of those cases are the method's own edges: past dS around 2 the correction has taken more than it can support, and at dS of 0 the ratio has no denominator.

--min-syn-subs is the third, a floor on the count of synonymous differences: a pair with one or two of them can return any ratio at all, and those pairs top an unfiltered table. dS is per site, so the same rate is weaker evidence in a short gene than in a long one.

Loading the blocks table in JBrowse

The output is a two-column pair table with the two rates after it, which is the .blocks shape MCScanBlocksAdapter reads. A self-comparison names one assembly twice, in blockAssemblies, in assemblyNames, and in both entries of bedLocations:

Config file CLI (add-track-json)

{
  "type": "SyntenyTrack",
  "trackId": "oat_homoeologs",
  "name": "Oat homoeologs (dN/dS)",
  "assemblyNames": ["oat", "oat"],
  "adapter": {
    "type": "MCScanBlocksAdapter",
    "uri": "oat.homoeologs.blocks.gz",
    "blockAssemblies": ["oat", "oat"],
    "bedLocations": [{ "uri": "oat.bed.gz" }, { "uri": "oat.bed.gz" }],
    "assemblyNames": ["oat", "oat"],
    "attributeColumns": ["dn", "ds", "syn_subs", "fisher_p"]
  }
}

jbrowse add-track-json '{
  "type": "SyntenyTrack",
  "trackId": "oat_homoeologs",
  "name": "Oat homoeologs (dN/dS)",
  "assemblyNames": ["oat", "oat"],
  "adapter": {
    "type": "MCScanBlocksAdapter",
    "uri": "oat.homoeologs.blocks.gz",
    "blockAssemblies": ["oat", "oat"],
    "bedLocations": [{ "uri": "oat.bed.gz" }, { "uri": "oat.bed.gz" }],
    "assemblyNames": ["oat", "oat"],
    "attributeColumns": ["dn", "ds", "syn_subs", "fisher_p"]
  }
}'

attributeColumns names the columns after the two gene columns. Each becomes a feature attribute, so it shows in the detail panel when a link is clicked, and dn with ds together drive the palette button's dN/dS. syn_subs and fisher_p are the evidence behind a colour: how many synonymous differences the ratio divided by, and a Fisher exact test against neutrality.

The ramp is pivoted at 1: below it a gene is under purifying selection, above it under positive selection. Its middle is 1 and its top is 2.

The session opens this as a dotplot, both axes the same genome in the same order, where the links resolve into the grid the subgenomes make.

Reading the plot

Every point off the diagonal is one chromosome's gene paired with its own copy on another chromosome, and the pattern those points make is the karyotype.

Oat's plot is on the right below and bread wheat's on the left, both hexaploid self-alignments over the same three homoeologous groups, drawn the same way.

Left, the bread wheat self-alignment; right, the oat one. Both hexaploids over homoeologous groups 4, 5 and 7, syntenic anchors coloured by dN/dS on a ramp pivoted at 1. Wheat's groups stay in their own blocks; oat pairs across groups throughout. Open in JBrowse: Open the oat plot ↗ (large dataset — this session takes a while to load) · Open the wheat plot ↗ (large dataset — this session takes a while to load)

The wheat panel comes from Ensembl Compara's own homoeolog calls (compara_to_blocks.py), so the two sides differ in assembly and in how the pairs were called as well as in species.

Checking the rates against the raw data

The script ends on the numbers behind the picture.

The control is dS. Oat's A and D subgenomes descend from closely related diploid Avena species and its C subgenome from a more distant one, so A-D pairs have to come out at a lower synonymous divergence than A-C or C-D. If all three land together, the rates are measuring the pipeline rather than the polyploidy.

Almost every pair here is blue, and the Fisher test in the fisher_p column supports the great majority of them. A ratio over 1 between two copies this recently separated rests on few substitutions, and the count clearing the test is close to what that many tests throw up by chance. A warm link is a gene worth a codon model; the primate walkthrough goes through that arithmetic on a locus small enough to check by eye.

The karyotype claim is a count: how many anchors join two chromosomes from different homoeologous groups, and how many chromosome pairs carry enough of them to be a segment. Wheat's translocations involve 4A, where oat's segments leave their group repeatedly.

Reproduce it end to end

build_oat_homoeologs.sh runs everything above in one shot: it downloads the annotation from Ensembl Plants, builds the BED and the proteome, runs DIAMOND and jcvi, measures dN and dS on every anchor, prints the tables in the section above, downloads JBrowse, and writes a config.json with the assembly, the track and a dotplot session.

curl -fO https://raw.githubusercontent.com/GMOD/jbrowse-components/main/scripts/build_oat_homoeologs.sh
bash build_oat_homoeologs.sh
npx --yes serve oat_homoeologs_build/jbrowse2  # then open the printed URL

It needs the tools under Prerequisites on PATH.

The wheat half of the two-hexaploid figure is a second script, taking the Compara route:

curl -fO https://raw.githubusercontent.com/GMOD/jbrowse-components/main/scripts/build_wheat_homoeologs.sh
bash build_wheat_homoeologs.sh   # writes ./wheat_homoeologs_build/

build_wheat_homoeologs.sh reads Ensembl Compara's homoeolog tables through compara_to_blocks.py, which it downloads itself; the pairs are already called, so no aligner runs.

References

Peng, Y. et al. Reference genome assemblies reveal the origin and evolution of allohexaploid oat. Nature Genetics 54, 1248-1258 (2022). https://doi.org/10.1038/s41588-022-01127-7
Nei, M. & Gojobori, T. Simple methods for estimating the numbers of synonymous and nonsynonymous nucleotide substitutions. Molecular Biology and Evolution 3, 418-426 (1986). https://doi.org/10.1093/oxfordjournals.molbev.a040410
Tang, H. et al. jcvi: A versatile toolkit for comparative genomics analysis. iMeta 3, e211 (2024). https://doi.org/10.1002/imt2.211
