Writing a no-build plugin

TL;DR: a no-build plugin is a single hand-edited .js file next to your config.json, referenced from the plugins array with esmLoc. It needs no bundler and no npm install, which makes it the right shape for jexl config callbacks or similar modifications — at the cost of no JSX, no TypeScript, and no dependencies beyond what JBrowse re-exports.

A "regular" plugin uses the plugin template and bundles dependencies with rollup. The only prerequisite here is a running JBrowse 2 instance to load the file into (see any of our quickstart guides).

Adding a jexl callback

Register a custom jexl function from your plugin's install(), to simplify config callbacks:

// a jexl function usable from any config callback, e.g.
// "jexl:customColor(feature)" as a track's color1
pluginManager.jexl.addFunction('customColor', feature => {
  if (feature.get('type') === 'exon') {
    return 'red'
  } else if (feature.get('type') === 'CDS') {
    return 'green'
  }
  return 'goldenrod'
})

Put myplugin.js alongside your config file and reference it in config.json:

{
  "plugins": [
    {
      "name": "MyPlugin",
      "esmLoc": {
        "uri": "myplugin.js"
      }
    }
  ],
  "tracks": []
}

Adding a global menu item

This adds a menu item via the plugin's configure method:

configure(pluginManager) {
  // configure runs in the web worker too, and there is no rootModel there —
  // so guard on it before touching any menu
  if (pluginManager.rootModel) {
    // a new menu in the top toolbar, at index 4
    pluginManager.rootModel.insertMenu('Citations', 4)

    pluginManager.rootModel.appendToMenu('Citations', {
      label: 'Cite this JBrowse session',
      onClick: session => {
        const widget = session.addWidget('CiteWidget', 'citeWidget', {})
        session.showWidget(widget)
      },
    })
  }
}

Importing with jbrequire

With no build step, reach the shared libraries JBrowse re-exports (React, MobX, MST, MUI, @jbrowse/core APIs) through jbrequire — e.g. const { types } = pluginManager.jbrequire('@jbrowse/mobx-state-tree'). The complete example below uses it five times. See Dependencies and re-exports and the canonical list.

Complete example

esmplugin.js

export default class MyPlugin {
  name = 'MyPlugin'
  version = '1.0'

  install(pluginManager) {
    // a jexl function usable from any config callback, e.g.
    // "jexl:customColor(feature)" as a track's color1
    pluginManager.jexl.addFunction('customColor', feature => {
      if (feature.get('type') === 'exon') {
        return 'red'
      } else if (feature.get('type') === 'CDS') {
        return 'green'
      }
      return 'goldenrod'
    })

    const { ConfigurationSchema } = pluginManager.jbrequire(
      '@jbrowse/core/configuration',
    )
    const WidgetType = pluginManager.jbrequire(
      '@jbrowse/core/pluggableElementTypes/WidgetType',
    )
    const { ElementId } = pluginManager.jbrequire(
      '@jbrowse/core/util/types/mst',
    )
    const { types } = pluginManager.jbrequire('@jbrowse/mobx-state-tree')

    const React = pluginManager.jbrequire('react')

    const CiteWidget = () => {
      // React.createElement rather than JSX: JSX needs a build step, which is
      // the one thing a no-build plugin does not have.
      const header = React.createElement(
        'h1',
        null,
        'Cite this JBrowse session',
      )
      const content = React.createElement(
        'p',
        null,
        'Diesh, Colin, et al. "JBrowse 2: a modular genome browser with views of synteny and structural variation." Genome Biology 24, 74 (2023).',
      )

      return React.createElement('div', null, header, content)
    }

    pluginManager.addWidgetType(() => {
      return new WidgetType({
        name: 'CiteWidget',
        heading: 'Cite this JBrowse session',
        configSchema: ConfigurationSchema('CiteWidget', {}),
        stateModel: types.model('CiteWidget', {
          id: ElementId,
          type: types.literal('CiteWidget'),
        }),
        ReactComponent: CiteWidget,
      })
    })
  }

  configure(pluginManager) {
    // configure runs in the web worker too, and there is no rootModel there —
    // so guard on it before touching any menu
    if (pluginManager.rootModel) {
      // a new menu in the top toolbar, at index 4
      pluginManager.rootModel.insertMenu('Citations', 4)

      pluginManager.rootModel.appendToMenu('Citations', {
        label: 'Cite this JBrowse session',
        onClick: session => {
          const widget = session.addWidget('CiteWidget', 'citeWidget', {})
          session.showWidget(widget)
        },
      })
    }
  }
}

Reference it from your config with esmLoc:

{
  "plugins": [
    {
      "name": "MyPlugin",
      "esmLoc": {
        "uri": "esmplugin.js"
      }
    }
  ],
  "tracks": []
}

The finished plugin

With the "Citation" plugin above in your config, the session looks like this:

Screenshot of a running JBrowse instance with the simple no build plugin added. Note our top level menu item has been added, and upon clicking it our widget opens. Open this view in JBrowse ↗

Note: JSX syntax

React without JSX is more verbose since JSX needs a build step. If your plugin has dependencies or you prefer TypeScript, use the plugin template, which includes a bundler and type checking.

Note: UMD vs ESM module syntax

This guide uses ESM modules (a plain exported class), supported by all modern browsers. For legacy browsers you can use UMD modules instead. See this example, which defines a global variable rather than exporting a class.

Note: Plugins in embedded React components

This guide targets jbrowse-web, which loads plugins via config.json. Embedded components (@jbrowse/react-app2 or @jbrowse/react-linear-genome-view2) have no config.json, so they take the class directly — declared in the same file, and passed in plugins:

export default function EmbeddedPlugin() {
  return (
    <JBrowse
      assemblies={assemblies}
      tracks={tracks}
      // the class itself, not a definition to fetch — an embedded app has no
      // config.json to list plugins in
      plugins={[HighlightRegionPlugin]}
      views={[
        {
          type: 'LinearGenomeView',
          init: {
            assembly: 'volvox',
            loc: 'ctgA:1..50000',
            tracks: ['volvox_cram'],
          },
        },
      ]}
    />
  )
}

createViewState({ config, plugins: [MyPlugin] }) takes the same array. To fetch a published plugin at runtime instead, loadPlugins returns records to pass through unchanged — see With external plugin.
